3 Axis CNC 2 Phase Closed Loop Stepper Motor Kit NEMA 23 Stepper Motor with Drives
Basic Info.
| Operate Mode | Two-Phase |
| Type | Magnetic-Electric |
| Certification | ISO9001, CCC |
| Brand | Umot |
| Axial Load | 15n |
| Rated Current | 2-3A |
| Radial Load | 75n(20mm From Flange) |
| Driver Current Range | 0~4A |
| Driver Input Voltage | DC 20V-50V |
| Rated Voltage | 1.6-1.62V |
| Insulation Resistance | 100mΩmin,500VDC |
| Axial Runout | 0.08max.(450g Load) |
| Radial Runout | 0.02max.(450g Load) |
| Step Angle | 1.8/0.9degree |
| Motor Length | 55~77mm |
| Transport Package | CTN |
| Specification | 57mm |
| Trademark | Umot |
| Origin | China |
| Production Capacity | 150000 Set / Month |
Product Description
Product Description
Motor Driver-UML244R- Fully closed-loop control technology using servo principle and a new 32-bit motor control dedicated DSP chip-According to the load operation, the current output is controlled in real time to minimize the heat generation of the motor- Can drive 57 series and 60 series hybrid servo motors- Compared with the open-loop stepper motor, the operation is smooth, the vibration is small, and the noise is low- The highest pulse response frequency can reach 200Kpps-Optical isolation signal input/output -High speed, high torque, high energy saving- The drive has an accurate running position memory function, no need to adjust when stopped- With overcurrent, overvoltage and tracking error out of tolerance protection- External 4-digit digital display tube, which can adjust parameters, electronic gear ratio, command filtering and other parameters through the display panelRotary Stepper Motor:The 2-phase hybrid rotary stepper motors offer an extremely strong, maintenance-free solution for applications requiring high starting torque and precision positioning when combined with stepper motor drive. They can be operated at very high resolutions depending on the subdivision of the step motor drive.These motors are available in standard NEMA motor sizes from NEMA 8 (20 mm flange), to NEMA 34 (86 mm flange).For all motors, a planetary gearbox is available. Also, special customization is available, such as special shaft, waterproof, and etc.Application:The motors can be used for positioning and speed control in a wide variety of applications, such as automation control, medical machine,3D printer, agricultural machinery and etc.
Product Parameters
Driver:
| Certification | ISO9001, CCC | Brand | Umot |
| Current Range | 0~4A | Input Voltage | DC 20V-50V |
| Highest Resolution | 40000PPR | Response Frequency | 200kpps |
| Control Mode | Pulse +Direction Cw+Ccw | Applicable Motor | NEMA 8, 11, 14, 17, 23, 24, 34 |
| Transport Package | CTN | Trademark | Umot |
| Origin | China | Production Capacity | 20000PCS/Year |
General Specifications:
| Step Angle: | 1.8°/0.9° | |||
| Temperature Rise : | 80ºC Max(Rated Current,2 phase power) | |||
| Ambient temperature: | -20ºC±120ºC | |||
| Insulation Resistance: | 100MΩMin,500VDC | |||
| Radial Runout: | 0.02Max.(450g load) | |||
| Axial Runout: | 0.08Max.(450g load) | |||
| Radial Load: | 75N(20mm from Flange) | |||
| Axial Load: | 15N | |||
Performance Specifications:
| Model No. | Motor Length | Current | Resistance | Rated | Holding Torque | Leads(No.) | Rotor Inertia | Mass |
| /Phase | /Phase | Voltage | ||||||
| (L)mm | A | Ω | V | mN.m | g.cm2 | Kg | ||
| 57HS0406 | 41 | 2.8 | 0.7 | 1.96 | 550 | 4 | 120 | 0.45 |
| 57HS5417 | 55 | 2 | 0.8 | 1.6 | 950 | 4 | 200 | 0.5 |
| 57HS7407 | 77 | 3 | 0.55 | 1.65 | 1600 | 4 | 230 | 0.6 |
| 57HS10402 | 100 | 4.2 | 0.7 | 2.94 | 3000 | 4 | 680 | 1.5 |
Parameters of Drawing
